What Is REST API? Examples And How To Use It: Crash Course System Design #3
Summary of What Is REST API? Examples And How To Use It: Crash Course System Design #3 from ByteByteGo · Published 2022-08-24 · Views: 1,421,795
This note was generated automatically from the video transcript.
TL;DR
REST (REpresentational State Transfer) is a set of architectural conventions—not a formal specification—that has dominated web API design since the early 2000s. It organizes resources behind unique URIs, maps HTTP verbs to CRUD operations, enforces statelessness, and relies on standard HTTP status codes, making it simple, scalable, and “good enough” for the vast majority of web and mobile backends.
Key Insights
- REST is not a specification; it is a set of conventions that became the de facto standard for web APIs in the early 2000s.
- Resources must be identified by nouns in the URI (e.g.,
/products), never by verbs (e.g.,/getAllProducts). - The four HTTP verbs—GET, POST, PUT, DELETE—map directly to the CRUD operations (Read, Create, Update, Delete).
- Statelessness is the critical architectural property: neither client nor server stores session context between requests, which is what makes horizontal scaling straightforward.
- Idempotency determines whether a failed request can be safely retried; POST (create) is typically not idempotent, while GET, PUT, and DELETE are.
- HTTP status codes follow a three-band convention: 2xx (success), 4xx (client error), 5xx (server error), and a well-behaved client may retry only on 5xx.
- Two practical completeness features round out a well-behaved REST API: pagination (
limit/offsetquery params) and URI versioning (e.g.,/v1/products).
Detailed Breakdown
What REST Is (and Is Not)
The video opens by clarifying a common misconception: REST is not a formal specification like SOAP or gRPC. It is a set of rules and conventions that became the common standard for building web APIs starting in the early 2000s. An API that follows these conventions is called a RESTful API. Real-world examples cited are Twilio, Stripe, and Google Maps.
The name itself—REpresentational State Transfer—describes the core idea: the client manipulates representations of server-side resources by transferring state (data) over HTTP.
Resources and URIs
A RESTful API organizes all data as resources, each addressed by a unique URI (Uniform Resource Identifier). The URI path differentiates resource types:
| Resource | URI |
|---|---|
| All products | /products |
| A single product | /products/42 |
| Orders for a user | /users/7/orders |
A critical rule: group by noun, not verb. The endpoint to fetch all products is /products, not /getAllProducts. The action is conveyed by the HTTP verb, not the path.
HTTP Verbs and CRUD
A client interacts with a resource by sending an HTTP request. The request line contains the HTTP verb followed by the URI:
GET /products/42 HTTP/1.1
POST /products HTTP/1.1
PUT /products/42 HTTP/1.1
DELETE /products/42 HTTP/1.1
The four verbs map to CRUD:
| Verb | CRUD | Purpose |
|---|---|---|
| GET | Read | Fetch data about an existing resource |
| POST | Create | Create a new resource |
| PUT | Update | Update (replace) an existing resource |
| DELETE | Delete | Remove an existing resource |
The request may include an optional body containing a custom payload, typically encoded in JSON. For example, a POST /products body might be {"name": "Widget", "price": 9.99}.
sequenceDiagram
participant C as Client
participant S as Server
C->>S: POST /products<br/>Body: {"name":"Widget","price":9.99}
S-->>C: 201 Created<br/>Body: {"id":43,"name":"Widget","price":9.99}
C->>S: GET /products/43
S-->>C: 200 OK<br/>Body: {"id":43,"name":"Widget","price":9.99}
C->>S: PUT /products/43<br/>Body: {"name":"Widget Pro","price":14.99}
S-->>C: 200 OK<br/>Body: {"id":43,"name":"Widget Pro","price":14.99}
C->>S: DELETE /products/43
S-->>C: 204 No Content
HTTP Status Codes
The first line of the server’s response carries an HTTP status code that tells the client what happened:
- 2xx – Request succeeded (e.g.,
200 OK,201 Created,204 No Content). - 4xx – Client-side error (e.g.,
400 Bad Requestfor malformed syntax,404 Not Found). - 5xx – Server-side error (e.g.,
503 Service Unavailable).
A well-behaved client may retry a request that returned a 5xx code. However, the video stresses the word may: retrying is only safe when the operation is idempotent.
Idempotency
An API operation is idempotent when making n identical requests has the same effect as making a single request.
- GET, PUT, DELETE are idempotent by design.
- POST (create) is generally not idempotent: sending the same
POST /productstwice creates two resources.
This distinction matters for retry logic. If a POST times out and the client blindly retries, it may create a duplicate. The video does not go into specific mitigation strategies (e.g., idempotency keys), but flags the risk explicitly.
Statelessness
The video calls statelessness a “critical attribute” of REST. It means:
- Neither the client nor the server stores any session or conversation state between requests.
- Every request–response cycle is fully independent of all others.
- Each request must carry all information the server needs (e.g., authentication tokens in headers).
The practical payoff: because no single server holds session state, you can place a load balancer in front of any number of identical server instances and route each request to whichever instance is free. This is what makes web applications easy to scale horizontally and “well behaved.”
flowchart LR
subgraph Client
A["Client (no session stored)"]
end
LB["Load Balancer"]
subgraph Server Pool
S1["Server 1"]
S2["Server 2"]
S3["Server N"]
end
DB[("Database")]
A -->|"Every request is self-contained"| LB
LB --> S1
LB --> S2
LB --> S3
S1 --> DB
S2 --> DB
S3 --> DB
Pagination
When an endpoint can return a very large collection (e.g., GET /products with millions of rows), the API should support pagination. The video describes the common limit/offset scheme:
GET /products?limit=20&offset=40
limit– maximum number of items to return.offset– number of items to skip (i.e., start from the 41st item).
If the client omits these parameters, the server should apply sensible defaults (the video does not specify exact defaults, but the convention is to cap the page size to avoid unbounded responses).
API Versioning
The video identifies versioning as essential for backward compatibility. When a breaking change is introduced, consumers need time to migrate. The most straightforward versioning strategy is to prefix the version in the URI:
/v1/products
/v2/products
This lets /v1/ and /v2/ coexist, so existing clients keep working while new clients adopt the updated contract. The video notes there are “many ways to version an API” but does not enumerate alternatives (header-based versioning, query-parameter versioning, etc.).
Positioning Among API Styles
The video closes by acknowledging that REST “may not be the best choice for all companies,” but its simplicity is precisely why it is so widely adopted. It briefly names GraphQL and gRPC as other popular API options, deferring a detailed comparison to separate videos.
Trade-offs and Gotchas
- POST is not idempotent. Blindly retrying a timed-out POST can create duplicate resources. Extra care (e.g., client-generated idempotency keys) is needed, though the video does not detail a specific mechanism.
- Statelessness eliminates server-side session memory. This simplifies scaling but pushes all context (auth tokens, user preferences) into every request, increasing payload size and requiring the client to manage its own state.
- Noun-only URIs can be awkward for operations that don’t map cleanly to CRUD (e.g., “cancel an order”). The video does not discuss sub-resource or action-URI workarounds.
- Pagination via limit/offset can become slow on very large datasets because the server must skip
offsetrows on every page. Cursor-based pagination is a common alternative, but it is not mentioned in the video. - URI versioning (
/v1/,/v2/) is simple but can lead to combinatorial explosion if many versions must be supported simultaneously. The video acknowledges “many ways to version” without elaborating. - REST is a convention, not a spec. There is no formal compliance test; two teams can both call their APIs “RESTful” while making very different design choices.
- Not a one-size-fits-all solution. The video explicitly states REST “may not be the best choice for all companies,” pointing to GraphQL and gRPC as alternatives for different use cases.
Takeaways
- Model your API around nouns (resources) in the URI and let HTTP verbs carry the action. Avoid verb-laden paths like
/getAllProducts. - Return correct HTTP status codes (2xx / 4xx / 5xx) so clients can implement proper error handling and retry logic.
- Keep your API stateless: every request must be self-contained. This is the single property that makes horizontal scaling trivial.
- Always support pagination (
limit/offsetwith sensible defaults) on list endpoints and version your API in the URI (/v1/...) to protect consumers from breaking changes. - Before reaching for REST, consider whether GraphQL (flexible querying) or gRPC (high-performance, typed contracts) better fits your latency, payload, or client-diversity requirements.
Glossary
- REST (REpresentational State Transfer): An architectural style for distributed systems where clients manipulate representations of server-side resources via HTTP; not a formal specification.
- URI (Uniform Resource Identifier): A string that uniquely identifies a resource on a server, e.g.,
/products/42. - CRUD: Create, Read, Update, Delete—the four fundamental data-manipulation operations mapped to POST, GET, PUT, DELETE.
- Idempotent: A property of an operation where repeating the same request any number of times yields the same result as a single execution.
- Stateless: An architectural property where neither client nor server retains session context between requests; each request is independent.
- Pagination: A technique of splitting a large result set into smaller pages, commonly via
limit(page size) andoffset(starting position) query parameters. - API Versioning: The practice of exposing multiple, coexisting versions of an API contract so that breaking changes do not immediately break existing consumers.
- GraphQL: A query language for APIs (by Facebook/Meta) that lets clients request exactly the fields they need in a single endpoint.
- gRPC: Google’s high-performance RPC framework using HTTP/2 and Protocol Buffers for typed, binary-serialized contracts.
